MH-400
Contact us for price
Specifications
| Manufacturer | Yida |
| Condition | New |
| Stock Number | 00053 |
| ITEM | MH-400 |
| Working Table Dimensions | 400 x 400 mm |
| Max. Loading Capacity | 400 kg |
| B Minimum Indexing | STD: 0.001° OPT: 1° |
| Pallet Capacity | 2 pcs |
| Max. Diameter of Workpiece | Ø550 |
| Max. Height of Workpiece | 800 mm |
| Max. Travel of X/Y/Z-axis | 550 / 510 / 630 mm |
| Distance from Spindle Nose to Table Center | 70-700 mm |
| Spindle Taper | ISO No. 40 |
| Spindle Speeds | STD: 10,000 rpm (belt-driven) OPT: 12,000 rpm (belt-driven) |
| Tool Capacity | STD: 40 pcs OPT: 60 /120 pcs |
