FM-600MH, FM-600ATC
Contact us for price
Description
The manufacturer reserves the right to modify the design, specifications, mechanisms…etc. to improve the performance of the machine without prior notice. All the specifications shown above are just for reference.
Specifications
| Manufacturer | Top Phoenix |
| Model | FM-600MH FM-600ATC |
| Condition | New |
| Stock Number | 00072 |
| Working surface | 813x3200mm (32"x126") |
| T-slots (size x number x pitch) | 18mmx7x100mm (0.709"x7x3.937") |
| Max. table load | 2200kgs (4840 lbs) |
| Longitudinal travel (X axis) | 3000mm (118-1/8") |
| Cross travel (Y axis) | 900mm (35-7/16") |
| Vertical travel (Z axis) | 750mm (29-1/2") |
| Distance from spindle end to table | 100~850mm (3-7/8"~33-7/16") |
| Distance from spindle center to column | 930mm (36-5/8") |
| Distance from floor to table surface | 955mm (37-9/16") |
| Spindle nose taper | BT50 |
| Spindle speeds | vari 4500 r.p.m. (or 6000 r.p.m., opt.) |
| Cutting feed rate (X, Y, Z axes) | 1~5000mm/min. (max.) |
| Rapid traverse (X, Y axes) | 10.0m/min. (max.) |
| Rapid traverse (Z axes) | 10.0m/min. (max.) |
| Gear ratio of motor pulley to ballscrew pulley on X, Y, Z axes | Direct coupled |
| Tool storage capacity | ─ 20pcs (carrousel) (or 24pcs, arm type, opt.) |
| Max. tool weight | ─ 15kgs (33.1 lbs) |
| Max. tool size (dia. x length) | ─ 125x300mm (4-7/8"x11-3/4") |
| Tool selection | ─ Random |
| Tool shank | ─ BT50 |
| Pull stud bolt | ─ MAS-P50T-1 |
| Distance from gauge line of tool holder to table | ─ 704mm (27-11/16") |
| Spindle motor (AC servo) | 15/18.5KW (or 18.5/22KW, opt.) |
| X, Y, Z axes motor | 5KW,MHMA, 2000 r.p.m. + i3 Speed Reducer |
| Coolant pump motor | AC 1/2HP |
| Gross weight (Approx.) | 21000kgs (46200 lbs) 21500kgs (47300 lbs) |
| Packing size (L x W x H) | 6000x2300x2550mm (236-3/16"x90-9/16"x100-3/8") +6250x2300x1060mm (246"x90-9/16"x41-11/16") |
