UZ-2000T2MW / UZ-2000T2W
Contact us for price
Description
Multi-Axis Machine for Mass Production
Specifications
| Model | UZ-2000T2MW UZ-2000T2W |
| Condition | New |
| Controller | FANUC 0i-T |
| Swing over bed | mm 660 660 |
| Swing over saddle | mm 620 620 |
| Max. Turning Diameter | mm 320 320 |
| Max. turning length | mm 790 790 |
| Guide way type | Linear + Box |
| Spindle Nose | ASA A2-5 A2-8 A2-11 A2-5 A2-8 A2-11 |
| Chuck Diameter | inch 6 10 15 6 10 15 |
| Bar Capacity | mm 52 78 105 52 78 105 |
| Spindle Speed | rpm 5000(Built-in) 3500(Belt) 2500(Belt) 5000(Built-in) 3500(Belt) 2500(Belt) |
| Spindle Motor Power | kW 11/15 (15/18.5) Cont. /30min |
| Tailstock body travel | mm 770 770 |
| Quill travel | mm 120 120 |
| Quill diameter | mm 85 85 |
| Quill taper | MT 5 5 |
| X1/X2 axis Travel | mm 210 210 |
| Z1/Z2 axis Travel | mm 840 840 |
| X1/X2 axis Rapid Traverse Rate | m/min 20 24 |
| Z1/Z2 axis Rapid Traverse Rate | m/min 36 40 |
| Tooling system | BMT-40 BMT-40 |
| Turret driven type | Servo mechanical |
| Number of tools | station 16+16 16+16 |
| Square tool shank size | mm 20 20 |
| Round tool shank size | mm 32 32 |
| Machine dimension LxWxH | m 5.1 x 2.4 x 2.4 5.1 x 2.4 x 2.4 |
| Net weight | kg 10500 10500 |
