ML-850
Contact us for price
Specifications
| Manufacturer | Ingenious Machinery |
| Model | STD: LS-320; OPT: LS-320SV STCI4032-W2- SMHDT32-460-530 |
| Condition | New |
| ITEM | UNIT ML-850 |
| Standard | C axis |
| Swing over bed | mm Φ850 |
| Swing over saddle | mm Φ600 |
| Maximum machining diameter | mm Φ720 / Φ600 Φ620 / Φ600 |
| Maximum machining length | mm STD: Φ720 x 150 + Φ600 x 1,100 620 x 190 + Φ600 x 1,030 |
| Slant angle of bed | 45° |
| X-axis | mm 380 (360+20) 380 (310+70) |
| Y-axis | mm – – |
| Z-axis | mm 1,330 1,290 |
| C-axis | ° – 360° (0.001°) |
| W-axis | mm – |
| Spindle speeds | rpm 50~2,000 (4-step gear box) |
| Spindle nose | STD: A2-11 |
| Spindle bore diameter | mm STD: Φ134 (A2-11) |
| Front bearing inner diameter | mm STD: Φ180 (A2-11) |
| Draw bar diameter | mm STD: Φ116; OPT: Φ120 |
| Chuck diameter | inch STD: 15″; OPT: 18″ |
| Type | Automatic |
| Stations | pcs STD: 12 |
| Square tool shank | mm 32 x 32 |
| Boring bar shank diameter | mm Φ50 |
| Indexing time (0~180°) | sec 3.2 2.71 |
| Spindle Speeds | rpm – 50~3,500 |
| Rapid Traverse | m/min X: 12, Z: 20 |
| Quill diameter | mm Φ125 |
| Quill bore taper | MT5 |
| Quill travel | mm 160 |
| Tailstock travel | mm 1,320 |
| Main-spindle | kw STD: α22 (22/26); OPT : α30 (30/37) |
| Sub-spindle | kw – |
| Live-tool | kw – α12/8000/ (11/15) |
| Axis servo motor | kw X/Z- α22 (4.0) |
| Hydraulic oil pump | kw 2.25 |
| Chip conveyor | kw 0.2 |
| Coolant pump | kw 0.8 |
| Positioning | mm ±0.005 |
| Repeatability | mm ±0.004 |
| Requirements | KVA 380-415/220V; STD: 30 KVA; OPT: 40 KVA |
| Height | cm 250 |
| Floor space (WxD) | cm 529 x 218 |
| Packing (w/conveyor) | cm 607 x 229 x 256 |
| Net weight (w/conveyor) | kg 11,820 |
| Gross weight (w/conveyor) | kg 12,600 |
