UM-120WB

Contact us for price
or
Call (519) 212-1782

Description

Vertical Machining Center STANDARD ACCESSORIES FANUC 0i-M controller + AICC II RJ-45 interface Rigid tapping Heat exchanger for electric cabinet 10.4" Colored LCD monitor Lubrication system 4-bar coolant system Cutter air blast Spray gun Three-color warning light Spindle oil cooling system OPTIONAL ACCESSORIES Data server 2G Linear scale (Heidenhain) Contact tool setter Workpiece touch probe 2-step gear box Air cooler for electric cabinet Spindle speed upgrading Upgrade to 15" Colored LCD monitor 20 bar coolant through spindle system Oil-coolant skimmer Oil mist collector 4th axis interface + FANUC motor & driver 4th axis rotary table Auto door Chain type chip conveyor + chip cart Transformer CE version
Show All

Specifications

ModelUM-120WB
ConditionNew
ControllerFANUC 0i-M
Spindle speedrpm 6000
Spindle nose taperBT50
Bearing inner diametermm 90
Drive systemBelt
X-axis travelmm 1200
Y-axis travelmm 650
Z-axis travelmm 600
Spindle nose to tablemm 150~750
Table dimensionmm 1300 x 650
T-slot(No. of T-slot x width x pitch)mm 5 x 18 x 120
Max. weight on tablekg 1200
X-axis Rapid Traverse Ratem / min 24
Y-axis Rapid Traverse Ratem / min 24
Z-axis Rapid Traverse Ratem / min 24
Cutting feed ratem / min 12
Ball screw diameter (X/Y/Z)mm 45/45/45
Guideway bearing typeBox
Tool magazine capacitypcs 24(32)
Max. tool weightkg 15
Max. tool diametermm 105
Max. tool diameter without adjacent toolsmm 210
Method of tool exchangeArm type
Max. tool lengthmm 300
AI contour controlAICC I
Spindle motor power(Cont. / 30min)kW 15/18.5
X/Y/Z feed motorkW 3/3/7
Coolant pump motor(50Hz/60Hz)kW 0.53+0.85/0.75+1.27
Air supplykg/cm² 5.5
Machine dimension L x W x Hm 3.3 x 2.7 x 3.0
Net weightkg 8000
